Proline Prosonic Flow 91W 超声波流量计

设备可通过自动频率扫描使测量性能达到较佳程度。配备具有出色成本效益的变送器。

Prosonic Flow W 捆绑式传感器专门针对水和污水的流量测量而设计。 与成本效益较佳且带有按键的 Prosonic Flow 91 变送器结合使用,将 Prosonic Flow 91W 打造成为水务行业流量监督的理想设备。

优势

·         投资成本低 - 管径越大(较大可达 DN 4000)投资的成本效益越好

·         不会造成泄漏 - 直接在管道外面进行测量

·         过程透明度高 – 具备诊断功能

·         经济型变送器 - 使用方便

·         调试快速可靠 - 可通过快速设置菜单完成安装

·         自动收集数据供维护使用

应用领域

·         在测量原理的选择时不需要考虑测量工况,包括压力、密度、温度和粘度等

·         针对生产过程用水、盐水、去矿物质水、饮用水和污水进行捆绑式测量.

设备特点:

·         介质温度: –20 to +80 °C (-4 to +176 °F)

·         防护等级IP68(6P型外壳),适合水下管道

·         根据IEC68-2-6标准,抗冲击和振动

·         铝质外壳用于变送器现场安装

·         显示屏可显示两行文字,带按键
Proline Prosonic Flow 91W Ultrasonic flowmeter The equipment can achieve better measurement performance through automatic frequency scanning. Equipped with excellent cost effective transmitter. Prosonic Flow W Strap-on sensors are designed specifically for water and sewage flow measurements. Used in conjunction with the cost-effective Prosonic Flow 91 transmitter with buttons, the Prosonic Flow 91W is built into the ideal device for flow monitoring in the water industry. advantage · Low investment cost - the larger the pipe diameter (up to DN 4000), the better the cost benefit of investment · No leakage - Measuring directly outside the pipe · High process transparency -- with diagnostic function · Economical transmitter - easy to use · Fast and reliable debugging - Installation can be completed through the Quick Settings menu · Automatically collect data for maintenance Application field · Measurement conditions, including pressure, density, temperature and viscosity, are not required to be considered in the selection of measurement principles · Bundle measurement for production water, brine, demineralized water, drinking water and sewage. Equipment features: · Medium temperature: -- 20 to +80 °C (-4 to +176 °F) · Protection class IP68(Type 6P housing), suitable for underwater pipelines
